Protocol Buffers Best Practices for Backward and Forward Compatibility

8 minute read     Updated:

John Gramila %     John Gramila

Protocol Buffers serialize structured data so it can be efficiently stored or shared over a network. They were designed for internal use at Google in 2001 and released to the public under an open-source license in 2008.

Protocol Buffers are compiled to a series of strictly arranged bytes, so they can be transmitted very efficiently. After reconstitution, they can also be understood by a wide range of languages. Let’s examine protobufs first at a high level, then do a deep dive into best practices for working with them to see if they’re a fit for your expanding data workflow.

What Exactly Are Protocol Buffers?

Protocol Buffers are designed with the concept of extensibility at their core. You can add fields without a care, though you do have to be attentive when modifying or removing fields. This article will go through how you can manage your messages to maintain forward and backward compatibility.

Protocol Buffers are most useful when regularly sharing small pieces of data (generally under 1 MB) between two computers on a regular basis. It’s designed for extracting and sharing that data, but it’s also very effective at storing data that will have to be shared between systems using different languages or controlled by different organizations.

Protocol Buffers are also great at persisting blobs of data, particularly in languages like C++ where you can use protobuf as a data struct. If you’re communicating with lots of computers a little at a time, Protocol Buffers will save you network bandwidth.

Understanding Backward and Forward Compatibility

Both backward and forward compatibility is important for any project you expect will run for a long time. There are at least two parts to any protobuf system, the sender and the receiver. If either one can be upgraded to a new message format, and the system functionality continues uninterrupted then the message protocol is both forward and backward compatible.

Backward Compatibility

If a client that was updated to a new message type but is still able to understand the previous message type then the message change is backward compatible. Backward compatibility is being able to understand messages from a previous version.

Forward Compatibility

If a message is changed and a non-updated client can still understand and process the message then the message change is forward compatible. Forward compatibility is being able to understand messages from a future version.

With Protocol buffers, if a sender is upgraded, the receiver can still understand messages if it is forward compatible. It can accept input crafted by later versions of protobuf. The sender is backward compatible because it’s creating output that can be consumed by earlier versions. So long as you’re careful about when and how you change and remove fields, your protobuf will be forward and backward compatible.

Getting Started with Buffers

The first step to making a Protocol Buffer is to define data structures in a .proto file. For each data structure you want to create, you’ll make a message that contains a name and data type for each field it contains.

syntax = "proto3";
package tutorial;

message Sample{
  string content = 1;
  int32 id = 2;
  string situation = 3;
}

These declarations in the .proto file are shared with both the message sender and receiver to construct immutable getters and setters that allow data to be read into and accessed from binary using a compiler, then accessed in a variety of programming languages.

Tips for Maintaining Compatibility

Compatibility starts with defining the syntax and version of protobuf the sender and receiver are using. The package makes sure your code is namespaced to avoid any collisions. It is possible to have a sender using proto3 while a receiver uses proto2 (or any other combination) as long as you’re careful about what fields you include. Both the sender and receiver have strict definitions of existing fields—you can make changes as long as you don’t disturb those definitions.

Create (Numerical) Order

From a compatibility perspective, unique field numbers are the most vital piece of the message declaration. These numbers (the = 1 after the name declaration) are used as identifiers for fields after they are converted to binary. When the message is decoded, a crucial step for compatibility is allowing the parser to skip fields it doesn’t recognize so it’s possible to add new fields without breaking programs that weren’t designed to look for them.

The unique field number is combined with a wire type corresponding to the data type of the field. This identifier and type combination form the key of every field in a message. These fields combined give the receiver the ability to uniquely identify fields and determine the length of the field, so it knows when to start looking for the next field.

This means once a unique field number or length is set, it cannot be changed. Any program consuming or serizalizing protobuf data needs the number to be fixed forever, or both the sender and all the receivers must be updated.

Encoding the numbers 1 through 15 takes one byte to encode, 16 through 2047 take two bytes, and so on. In situations where the size of messages is important, the most frequently exchanged data should have the smallest field numbers. The language is designed to effectively handle new fields, but because you can’t change the identifier of fields, it may be wise to leave yourself a couple gaps in these high-efficiency identifier ranges in case a very common field pops up in the future.

One of the best ways to prevent problems with overlapping or misunderstood field numbers is to use the reserved keyword. If you wanted to remove the type field in your Sample message, any applications running the protobuf version that contained that field would break if the identifier was removed and then reused for some other field.

To get around these compatibility issues, you can reserve identifiers. You can also reserve ranges of identifiers; here you’re reserving a range and the removed value of 1:

message Sample{
  reserved 1, 5 to 8;
  int32 id = 2;
  string text = 3;
}

Beware of Required Fields

Another tricky part of compatibility is the required modifier preceding the data type. In the second version of protobuf, there were three modifiers to choose from: optional, repeated, and required. The required option was removed in protobuf3, because it requires careful planning to ensure compatibility. If a required field is missing from a message, readers will consider the message incomplete and return an error.

Instead, consider writing custom validation or use default values within your application to handle required fields. In protobuf2, you were able to set default values, in protobuf3, every field type has a fixed default value.

Avoid Groups

Another feature of protobuf2 that should be avoided to ensure compatibility is Groups. These enable nesting information inside method definitions. A Group combines a nested message type and a field into a single declaration using the group keyword.

The recommended way to nest messages is to nest them, then call them:

message SampleContainer {
message Sample{
  optional int32 id = 2;
  optional string text = 3;
}
   repeated Sample samples = 1;
}

The difference between nested message types and Groups is the wire format they use.

Adding New Fields

New fields can be safely added in any version of protobuf, but there are still compatibility considerations to be aware of. Pay attention to the depreciation of the required fields and transition from user-specified defaults to protobuf-specified defaults. The application receiving protobuf data has to be responsible for handling the default values for any new fields.

You generally can freely change the name and order of fields. However, when you’re producing JSON serialized data with protobuf, the field names are also reserved by the receiver. This requires users to reserve field identifiers and names when removing or deprecating fields.

Keep an Eye on Compatibility When Changing Field Types

Because field types are also used to determine when the receiver ends a field, changing field types across versions without carefully checking for compatibility can also cause problems. There are many specific rules about how to change field types, but a good standard is to avoid ever changing the wire type of any field. If you’re in a situation where you need to change a field type, the best path forward is to deprecate the existing field and put the new information into a new field.

Don’t Destroy, Deprecate

Protocol Buffer compatibility problems generally start when you need to change the length of or remove existing fields. There are a whole host of rules about how fields can change.

Largely, maintaining backward and forward compatibility comes down to maintaining a consistent wire type. You can’t change the wire type or alter the length of fields and expect old code to properly send or receive messages—the sender’s and receiver’s understanding of the exact length of each element in the transmitted messages needs to be precise.

Type Meaning Used For
0 Varint int32, int64, uint32, uint64, sint32, sint64, bool, enum
1 64-bit fixed64, sfixed64, double
2 Length-delimited string, bytes, embedded messages, packed repeated fields
3 Start group groups (deprecated)
4 End group groups (deprecated)
5 32-bit fixed32, sfixed32, float
Protobuf Wire Types

Conclusion

The biggest problems when upgrading are mismatching required fields or a need to change field types. In the short term, adding other fields is a viable solution, but at a certain point, the marginal cost of that solution becomes more of a burden than auditing and upgrading your services.

Protocol Buffers are a relatively young technology, so changes now will have long-lasting implications. Compatibility issues do exist between versions, but they’re possible to step around if you’re careful. As always, make life simpler by planning out your data structures in advance. Once things eventually do change, the safest method for modifying fields is to add a new one and deprecate the old field.

To deprecate a field, you can change the name to something deprecated or remove it and reserve the identifier. If you really want to change a field type, and you’re able to follow the correct version of the rules, remember to never change the numerical identifier for that field. Plan well, and it’ll be easy to maintain backward and forward compatibility for your Protocol Buffer deployment.
